Insulation: Polyvinyl Chloride (PVC)
Shield: Overall Shield with Foil
Jacket: Polyvinyl Chloride (PVC)
Color Coding: Insulation - Black, White, Red, Green, Yellow or others upon request
Jacket - Red, Black or others upon request
File Listing No.: 300938
Application:
Wiring for fire alarm, signaling, and voice communication circuits
Concealed wiring in dry locations
Exposed wiring in dry locations
Use in cable trays in dry locations
Use in any raceway or cable tray
Suitable for embedding in plaster finishes over brick or masonry
(not recommendedfor damp or wet locations)
Features:
Rated for temperature range of -20°C to 105°C
Excellent crush resistance
Provides long service life
Cost effective alternative to installations in conduit
Ripcord under jacket for jobsite ease of use
Themaximum voltage rating for all intended applications is 300 volts.
Compliances:
CSA C22.2 No. 208
CSA C22.2 No. 2556
Sunlight-Resistant
RoHS compliant
Rated at FT4 flame test
