Insulation: Polyvinyl Chloride (PVC)
Jacket: Polyvinyl Chloride (PVC)
Colur Coding: Insulation - Black, White, Red, Green, Yellow or others upon request
Jacket - Red, Grey, Brown or others upon request
File Listing No.: 300938
Application:
For extra-low-voltage Class 2 circuits limited to 30V as per CEC Part I 2018,
Rules 16-200 and 16-210 and CSA C22.2 No. 223.
Use in exposed or concealed wiring or raceways, in dry or damp locations.
Features:
Two or more fully annealed bare solid copper conductors
Insulation/Jacket: Premium-grade PVC -20°C to +60°C
Ripcord under jacket for jobsite ease of use
Final assembly: flat or round construction for easy tear-down during installation
Compliances:
CSA C22.2 No. 35 Type LVT
CSA C22.2 No. 2556
Sunlight-Resistant
RoHS Compliant
Rated at FT4 flame test
