Insulation: Cross-Linked Polyethylene (XLPE), Type RWU90
Color Coding: Standard black, red, green; other colors available upon request
File Listing No.: 300938
Application:
Designed for direct earth burial (with protection as required by the inspecting authority).
Suitable for above-ground or underground installations.
Approved for ventilated raceway systems.
Approved for dry, damp, and wet locations; Ceiling air-handling plenums; Exposed and
concealed wiring
Temperature Range:
Installation: -40°C (-40°F) minimum (with proper handling)
Operation: 90°C (194°F) maximum conductor temperature
Features:
Conductor: Stranded copper
Insulation: Extra-thick, moisture-resistant, low-temperature XLPE
Voltage Rating: 1000V
Environmental Compliance: Lead-free, RoHS-compliant
Sunlight-resistant (SR) in all standard colors
Compliance Standards:
CSA C22.2 No. 38
CSA C22.2 No. 2556
Sunlight Resistant
RoHS Compliant
