Insulation: XLPE Type RW90
Colur Coding: Black or other colours available upon request.
File Listing No.: 300938
Application:
- Designed for direct earth burial (with protection as required by the Canadian Electrical
- Code Part I)
- Can also be used for open wiring, used in raceways for service entrance above or under ground.
- Minimum recommended installation temperature minus 40°C (with suitable handling procedures).
- Maximum conductor temperature 90°C
- Approved for use with ceiling fixtures.
Features:
8000 Series ACM Aluminum Class B stranded conductor with extra thickness on the moisture resistant, low temperature, cross linked polyethylene (XLPE) insulation. Rated at 600 volts. Lead free and RoHs compliant
Compliances: CSA C22.2 No. 38
UL44
CSA C22.2 No. 2556
Sunlight Resistant
RoHS
