Conductor: Bare copper conductors for excellent conductivity and low voltage drop
Insulation: High Density Polyethylene (HDPE)
Shield: Overall shield with tinned copper braid or foil
Jacket: Polyvinyl Chloride (PVC)
Color: Grey, Blue, Yellow or upon request
File Listing No.: 300938
Application:
It is a high performance data communication cable. This Ethernet cable is designed for indoor and riser
network installations of type CMR (Riser rated communication cable), may be used in Ethernet Networking
system, PoE applications, Video MPEG4 / MJPEG / Digital / Analog / Baseband / Broadband and other
Multimedia Voice applications. It supports networks up to 10 Gigabit Ethernet.
Features:
Vertical and Horizontal backbone cable.
Transmission of digital and analog signals for data, video and audio applications.
IEEE 802.3ab 1000BASE-T, 1000BASE-TX and legacy speeds.
CDDI / ATM / Token Ring.
IEEE 802.3af (PoE) / IEEE 802.3at (PoE+).
For use in communication circuits
when exposed, concealed, or installed
in raceways. Rated at 300 volts.
Compliances:
CSA C22.2 No. 214 Communication Cables
UL 444–Communication Cables, Type CMR
UL 1666–Riser Rated
Flame Test FT4
RoHS Compliant
