Insulation: 90°C-rated cross-linked polyethylene (XLPE, Type RW90)
Insulated ground: Green-colored copper conductor
Bonding conductor: Bare copper (CSA C22.2 No. 51 compliant)
Armor: Interlocked aluminum armor
Color Coding: Black, White, Red (phase identification)
File Listing No.: 300938
Applications:
Approved for dry and wet locations.
Healthcare facilities (hospitals, operating rooms)
Data centers and computer rooms
Commercial/industrial power distribution
Complies with CEA Z015 Rules 24-102/24-104 (medical area safety standards)
Suitable for sensitive electronic equipment (isolated ground systems)
Features:
Configuration: 2-3 insulated conductors + insulated ground + bare bonding conductor
Voltage Rating: 600V AC
Continuous operation: -40°C to +90°C (wet/dry locations)
Minimum installation temperature: -10°C
Cold bend/impact tested at -40°C
FT4 flame test / ST1 smoke emission
Standards Compliance:
CSA Standard C22.2 No. 51
CSA Standard C22.2 No. 38
CSA Standard C22.2 No. 2556
ST1-FT4 Rating
RoHS compliant
