Insulation: 90°C-rated XLPE (Type RW90)
Inner Jacket: Black PVC (moisture barrier)
Armor: Interlocked aluminum
Outer Jacket: Black UV-resistant PVC
Grounding: Bare copper bonding conductor
Color Coding: Black, White, Red, Blue (phase identification per CEC 4-032)
File Listing No.: 300938
Applications:
Hazardous Locations: Class I/II/III, Div. 1 & 2 (CEC 2024 Section 18)
Installate for cable trays (ventilated/non-ventilated/ladder-type);
Direct burial (with corrosion protection) and service entrance (above/below ground)
Suitable for Wet/dry locations (NEMA 3R/4X);
Corrosive atmospheres (with compatible glands) and Outdoor exposure (Sunlight resistant jacket).
Voltage: 600V or 1000V options for flexible applications
Safety: FT4 rating for fire-resistant circuits in HL areas
Standards Compliance：
CSA Standard C22.2 No. 38 (XLPE Insulation)
CSA C22.2 No. 131 (TECK90 Cable Type)
CSA C22.2 No. 174 (Hazardous Location Cables)
CSA Standard C22.2 No. 2556
FT4 flame test
RoHS Compliant
