Insulation: Cross-linked Polyethylene (XLPE) Type RPVU90
Colur Coding: Standard black, red; other colors available upon request
File Listing No.: 300938
Application:
PV system interconnections compliant with CEC Part I Section 64-210.
Suitable for exposed wiring in raceways; Cable tray installations;
Wet and dry locations and direct burial (with approved mechanical protection).
Rated at 2000V DC
Temperature range:
Operation: -40°C to +90°C (wet/dry conditions)
Installation: -25°C (minimum with proper handling)
Cold bend test: -40°C (CSA compliant)
Sunlight resistant (UV stabilized)
Lead-free compliant with RoHS
Features:
Single-core copper conductor class B standed
Enhanced moisture-resistant XLPE insulation
Arctic-grade flexibility (-40°C cold bend performance)
UV-resistant for long-term outdoor exposure
Rated for both exposed and concealed
PV installations
Compliance Standards:
CSA C22.2 No. 38
CSA C22.2 No. 271
CSA C22.2 No. 2556
Sunlight Resistant
RoHS Compliant
