Insulation/Jacket: Polyvinyl Chloride (PVC)
Colour Coding: Insulation - Blue, Brown, Yellow+Green or others upon request.
Jacket - White, Black or others upon request.
CCC Certification No.: 2010010105413710
Applications: This type is mainly used for controlling signal transmission lines, electrical equipment, instruments, automation equipment, security and anti-theft alarm systems, high-rise building intercom systems, household lighting connection lines, etc.
Features:
Using high-purity oxygen free copper wire then twisted together, with strong antioxidant ability, softness, and low electrical resistivity.
With national standard 70 degree PVC material, great at tensile strength(>15N/mm²), tensile elongation(>250%) by insulation and tensile strength(>16N/mm²), tensile elongation(>280%) by jacket, anti-aging resistant,strong corrosion resistance and no cracking at low temperature.
Sufficient conductor diameter, better current carrying capacity.
Can be soaked in seawater for a long time, the jacket material will not age or crack.
Advanced spray printing technology for content printing, number of meters and cutting position, making it easy for customers to retail the wire by meter, ensuring sufficient length of each roll.
Compliances:
IEC60227-5:2003
GB/T5023.5-2008
JB/T8734.3-2016
Q/WA 3
